Introduction

The organ in Main Auditorium of Boardwalk Hall (formerly Convention Hall) was built by the Midmer-Losh Co., of Merrick, Long Island, New York. Work on the instrument, opus 5550, started in May of 1929 and was completed in December, 1932. The specifications were drawn-up by Emerson L. Richards (18841963), a native of Atlantic City and State Senator for Atlantic County. Although politics was his profession, pipe organs were his passion and pre-occupation. He described himself as an "Organ Architect" and, over the years, had some 80 articles published in organ journals. As a result of his design ideas and the practical demonstrations thereof, his influence extended far beyond Atlantic City, and he was dubbed "the Commander-in-Chief of the American Revolution in Organ Building".

The Main Auditorium is a vast space, measuring 488 feet long, 288 feet wide, and 137 feet high. To fill the place with sound, Richards designed an organ with some mind-boggling and previously unheard of specifications. There are ten 32-foot ranks, a full-length 64-foot (one of only two in the world see Note 1, at the end of this page), four voices on 100-inch wind (a pressure not employed in any other organ) and 10 on 50 inches. With a total 33,116 pipes (see Note 2), the organ is the largest (and loudest!) musical instrument on Earth.

The pipes are accommodated in eight chambers arranged in opposite pairs on the left and right sides of the auditorium there being four chambers in the stage area and four near the center of the room. The simplified diagram (not to scale), below, shows the contents of the chambers and gives an idea their relative locations.
LEFT STAGE
Pedal Left
Swell*
Swell-Choir*
Unenclosed Choir
String I*
STAGE RIGHT STAGE
Pedal Right
Great
Great-Solo**
Solo*
Percussion
LEFT FORWARD
Choir*
RIGHT FORWARD
Brass Chorus*
String II*
LEFT CENTER
Gallery III
Gallery IV*
LEFT UPPER
Fanfare***
String III***
Upper Chambers
are located above the
Center Chambers
RIGHT UPPER
Echo*
RIGHT CENTER
Gallery I*
Gallery II*
* In its own swell box. ** In two seperate swell boxes. *** In a shared swell box.
The main console is located to the right of the stage, near the proscenium arch. Its seven manuals are called, from bottom to top: Choir, Great, Swell, Solo, Fanfare, Echo, Bombard. There are 1,235 stop-keys, consisting of 852 speaking registers, 35 melodic percussions, 46 non-melodic percussions, 18 tremolos, 164 couplers, and 120 swell pedal selectives for switching the shades of the swell boxes onto the six swell pedals (a seventh pedal is the crescendo). N.B. There were originally to be 15 swell boxes but, in the event, the Percussion department (to have been in swell box number 10) was unenclosed and the String III organ (planned for swell box number 15) was placed inside the Fanfare organ's box. Consequently, there are now only 13 swell boxes, although the stop-keys for the additional two are provided for.

The list of registers on this console is given below. The wind pressure of 100-inch stops is shown in red and that of 50-inch is in green the stop-keys of these voices have red or green jewels, as appropriate, set in them. Derivations are indicated in writing and by the stop numbers, at left (immediately before the stop's name).
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL RIGHTTotals: 11 voices / 11 ranks / 903 pipes
117Diaphone6435" windfrom Dulzian
221Sub Principal3220" windfrom Sub Principal, Great
31Contra Tibia Clausa3220" windextended97 pipes
41Tibia Quint211/320" windext. Contra Tibia Clausa
52Diaphone Phonon1650" windextended39 pipes
64Principal1630" windextended109 pipes
721Diapason1620" windfrom Sub Principal, Great
822Diapason1620" windfrom Double Diapason I, Great
982Geigen Diapason1620" windfrom Geigen Diapason, Great-Solo
103Tibia Major1630" windextended85 pipes
1159Major Flute1630" windfrom Major Flute, Solo
1283Wald Flute1615" windfrom Wald Flute, Great-Solo
131Grand Bourdon1620" windext. Contra Tibia Clausa
141Tibia Clausa1615" windfrom Tibia Clausa, Great-Solo
155Viol1630" windextended85 pipes
166Gross Tierce124/520" windextended68 pipes
172Diaphone Quint102/350" windext. Diaphone Phonon
184Principal Quint102/330" windext. Principal
193Tibia Quint102/330" windext. Tibia Major
201Tibia Quint102/320" windext. Contra Tibia Clausa
2183Quint Minor102/315" windfrom Tibia Clausa, Great-Solo
227Septieme91/720" windextended68 pipes
234Octave Principal830" windext. Principal
2422Octave Major820" windfrom Double Diapason I, Great
2585Octave Diapason815" windfrom Horn Diapason, Great-Solo
2685Octave Geigen815" windfrom Geigen Diapason, Great-Solo
2787Gross Gemshorn815" windfrom Gemshorn, Great-Solo
283Tibia Major830" windext. Tibia Major
291Tibia Clausa820" windext. Tibia Clausa
3086Doppel Gedeckt815" windfrom Doppel Gedeckt, Great-Solo
315Viol830" windext. Viol
326Gross Tierce62/520" windext. Gross Tierce
334Principal Quint51/330" windext. Principal
343Tibia Quint51/330" windext. Tibia Major
351Tibia Quint51/320" windext. Contra Tibia Clausa
367Gross Septieme44/720" windext. Septieme
374Super Octave430" windext. Principal
3885Fifteenth415" windfrom Horn Diapason, Great-Solo
393Tibia Fifteenth430" windext. Tibia Major
401Flute Fifteenth420" windext. Contra Tibia Clausa
415Viol Fifteenth430" windext. Viol
426Tierce31/520" windext. Gross Tierce
433Tibia Nineteenth22/320" windext. Tibia Major
441Flute Nineteenth22/320" windext. Contra Tibia Clausa
455Viol Nineteenth22/330" windext. Viol
467Septieme22/720" windext. Septieme
473Tibia Twenty-Second230" windext. Tibia Major
4881Flageolet215" windfrom Wald Flute, Great-Solo
496Octave Tierce13/520" windext. Gross Tierce
503Tibia Twenty-Sixth11/330" windext. Tibia Major
517Octave Septieme11/720" windext. Septieme
521Flute Twenty-Ninth120" windext. Contra Tibia Clausa
53MixtureXI15" windfrom various Great-Solo ranks
54Reed MixtureV15" windfrom various Great-Solo ranks
5517Dulzian6435" windextended85 pipes
5617Contra Dulz Quint422/335" windext. Dulzian
5717Contra Bombardon3235" windext. Bombardon
5817Contra Dulzian3235" windext. Dulzian
5917Dulzian Quint211/335" windext. Dulzian
609Grand Ophicleide16100" windextended85 pipes
6173Tuba Magna1650" windfrom Tuba Magna, Solo
628Bombardon1635" windextended85 pipes
6374Trumpet Profunda1630" windfrom Trumpet Profunda, Solo
6417Dulzian1635" windext. Dulzian
6510Trumpet1620" windextended97 pipes
6696Saxophone1615" windfrom Saxophone, Great-Solo
6798French Horn1615" windfrom French Horn, Great-Solo
6897English Horn1615" windfrom English Horn, Great-Solo
6995Oboe Horn1615" windfrom Oboie Horn, Great-Solo
70100Krummhorn1615" windfrom Krummhorn, Great-Solo
7199Vox Baryton1615" windfrom Vox Baryton, Great-Solo
728Bombard Quint102/335" windext. Bombardon
7317Dulzian Quint102/335" windext. Dulzian
749Ophicleide8100" windext. Grand Ophicleide
7578Bugle850" windfrom Bugle, Solo
768Octave Bombardon835" windext. Bombardon
778Octave Dulzian835" windext. Dulzian
7810Octave Trumpet820" windext. Trumpet
79100Krummhorn815" windfrom Krummhorn, Great-Solo
8099Vox Baryton815" windfrom Vox Baryton, Great-Solo
818Bombardon Quint51/335" windext. Bombardon
8210Trumpet Quint51/320" windext. Trumpet
8317Dulzian Fifteenth435" windext. Dulzian
848Trumpet Fifteenth420" windext. Trumpet
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL LEFTTotals: 10 voices / 16 ranks / 955 pipes
111Diaphone3250" windext. Diaphone
212Diapason3220" windext. Diapason
311Diaphone1650" windextended97 pipes
413Diaphonic Diapason1635" windextended85 pipes
5320Major Diapason1620" windstraight32 pipes
612Diapason1620" windextended97 pipes
7117Diapason1620" windext. Double Diapason, Swell
815Tibia Clausa1620" windextended85 pipes
9147Doppel Gedeckt1615" windext. Doppel Gedeckt, Swell-Choir
10311Stoppped Diapason1615" windext. Stopped Diapason, Swell-Choir
1114Bass Viol1620" windextended85 pipes
12254Bass Viol1625" windfrom Contra Basso, String I
13131Bass Gamba1615" windfrom Contra Gamba, Swell
14148Cone Gamba1615" windfrom Cone Gamba, Swell-Choir
1512Diapason Quint102/320" windext. Diapason
16311Stopped Quint102/315" windfrom Stopped Diapason, Swell-Choir
17148Cone Quint102/315" windfrom Cone Gamba, Swell-Choir
1811Octave Diaphone850" windext. Diaphone
1913Octave Diapason835" windext. Diapason Phonon
2012Octave Phonon820" windext. Diapason
2115Gross Flute820" windext. Tibia Clausa
22152Octave Gemshorn815" windext. Gemshorn, Swell-Choir
23149Clarabella815" windext. Clarabella, Swell-Choir
2414Cello820" windext. Bass Viol
25155Tenth62/510" windfrom Third, Swell-Choir
26156Twelfth51/310" windfrom Fifth, Swell-Choir
27157Fourteenth44/710" windfrom Seventh, Swell-Choir
2811Fifteenth450" windext. Diaphone
2912Super Octave420" windext. Diapason
30152Gemshorn Fifteenth415" windfrom Gemshorn, Swell-Choir
3115Flute Fifteenth420" windext. Tibia Clausa
32155Seventeenth31/510" windfrom Third, Swell-Choir
33156Nineteenth22/310" windfrom Fifth, Swell-Choir
34157Twenty-First22/710" windfrom Seventh, Swell-Choir
3512Twenty-Second220" windext. Diapason
36152Gemshorn Twenty-Second215" windfrom Gemshorn, Swell-Choir
3715Twenty-Second220" windext. Tibia Clausa
3815Twenty-Ninth120" windext. Tibia Clausa
3916Stentor Sesquialtera 822VII20" windstraight224 pipes
40Grave Mixture 119VI15" windfrom various Swell and Swell-Choir ranks224 pipes
4118Contra Bombard3250" windext. Bombard
4219Contra Fagotto3220" windext. Fagotto
4320Major Posaune1650" windextended44 pipes
4418Bombard1650" windextended97 pipes
45138Trumpet1630" windfrom Double Trumpet, Swell
46142Horn1615" windfrom Double Horn, Swell
4719Fagotto1620" windextended109 pipes
48160Oboe1615" windfrom Oboe, Swell-Choir
49161Clarinet1615" windfrom Clarinet, Swell-Choir
50162Vox Humana1615" windfrom Vox Humana, Swell-Choir
5120Major Posaune850" windext. Major Posaune
5218Octave Bombard850" windext. Bombard
5319Octave Fagotto820" windext. Fagotto
54160Octave Oboe815" windfrom Oboe, Swell-Choir
55161Octave Clarinet815" windfrom Clarinet, Swell-Choir
5619Horn Twelfth51/320" windext. Fagotto
5718Bombard Fifteenth450" windext. Bombard
5819Horn Fifteenth420" windext. Fagotto
59160Oboe Fifteenth415" windfrom Oboe, Swell-Choir
6019Horn Nineteenth22/320" windext. Fagotto
6119Fagotto Twenty-Second220" windext. Fagotto
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL RIGHT GALLERY
1298Contra Violone3225" windfrom Violone, Echo
2233Diaphone1625" windfrom Diaphone, Gallery I
3242Flute Maggiore1625" windfrom Flute Maggiore, Gallery II
4214Spire Flute1615" windfrom Spire Flute, Echo
5220Bourdon1615" windfrom Clarabella, Echo
6298Contra Violone1625" windfrom Violone, Echo
7265Double Bass1615" windfrom Double Bass, String II
8266Contra Bass1615" windfrom Contra Bass, String II
9267Contra Viol1615" windfrom Contra Viol, String II
10213Contra Gamba1615" windfrom Gamba, Echo
11220Flute Quint102/315" windfrom Clarabella, Echo
12214Cone Flute825" windext. Spire Flute, Echo
13298Violone825" windfrom Violone, Echo
14298Violone425" windfrom Violone, Echo
15235Trumpet Sonora16100" windfrom Trumpet Mirabilis, Gallery I
16231Tuba d'Amour1625" windfrom Tuba d'Amour, Echo
17226Contra Bassoon1615" windfrom Bassoon, Echo
18226Chalumeau1615" windfrom Clarinet, Echo
19230Vox Humana1615" windfrom Vox Humana II, Echo
20226Bassoon815" windfrom Bassoon, Echo
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL LEFT GALLERY
1236Grand Diapason1620" windfrom Contra Diapason, Gallery III
2171Dulciana1610" windfrom Contra Dulciana, Choir
3197Major Flute1620" windfrom Major Flute, Fanfare
4176Double Melodia1610" windfrom Melodia, Choir
5176Melodia810" windfrom Melodia, Choir
6299Contra Trombone3235" windfrom Trombone, Fanfare
7205Posaune1650" windfrom Posaune, Fanfare
8299Trombone1635" windfrom Trombone, Fanfare
9206Bombardon1635" windfrom Bombardon, Fanfare
10188Trombone1625" windfrom Contra Tromba, Choir
11249Saxophone1625" windfrom Saxophone, Gallery IV
12209Tromba Quint102/320" windfrom Tromba Quint, Fanfare
13299Trombone835" windfrom Trombone, Fanfare
14188Tromba825" windfrom Contra Tromba, Choir
15210Tromba Tierce62/520" windfrom Tromba Tierce, Fanfare
16209Tromba Quint51/320" windfrom Tromba Quint, Fanfare
17210Tromba Seventeenth31/520" windfrom Tromba Tierce, Fanfare
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL COUPLERS
1Pedal Divide
2Choir to Pedal8
3Choir to Pedal4
4Great to Pedal8
5Great to Pedal4
6Swell to Pedal8
7Swell to Pedal4
8Solo to Pedal8
9Solo to Pedal4
10Fanfare to Pedal8
11Fanfare to Pedal4
12Echo to Pedal8
13Gallery I to Pedal
14Gallery II to Pedal
15Gallery III to Pedal
16Gallery IV to Pedal
17Brass Chorus to Pedal
18String I to Pedal
19String II to Pedal
20String III to Pedal
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL PERCUSSION
1AGrand Piano16from Grand Piano, in Left Center Chamber
2AGrand Piano8from Grand Piano, in Left Center Chamber
3108Chimes8from Great-Solo, unenclosed
4BContra Drum StrikeFFfrom Percussion
5BContra Drum RollFFfrom Percussion
6BContra Drum StrikeMPfrom Percussion
7BContra Drum RollMPfrom Percussion
8CBass Drum Strikefrom Percussion
9CBass Drum Rollfrom Percussion
10CBass Drum Strikefrom Percussion
11CBass Drum Rollfrom Percussion
12DBass Drum Strikefrom Percussion
13DBass Drum Rollfrom Percussion
14F,GSnare Drums Rollfrom Percussion
15ESnare Drum Rollfrom Percussion
16IChinese Gong Strikefrom Percussion
17IChinese Gong Rollfrom Percussion
18HCymbalfrom Percussion
19JPersian Cymbalfrom Percussion
20KPersian Cymbalfrom Percussion
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
PEDAL 2ND TOUCH
117Diaphone6435" windfrom Dulzian, Pedal Right
211Diaphone3250" windfrom Diaphone, Pedal Left
313Diaphonic Diapason1635" windfrom Diaphonic Diapason, Pedal Left
43Tibia Major1630" windfrom Tibia Major, Pedal Right
55Contra Viol1630" windfrom Viol, Pedal Right
63Tibia Major830" windfrom Tibia Major, Pedal Right
75Viol830" windfrom Viol, Pedal Right
83Tibia Major430" windfrom Tibia Major, Pedal Right
95Viol430" windfrom Viol, Pedal Right
1017Dulzian6435" windfrom Dulzian, Pedal Right
1118Contra Bombard3250" windfrom Bombard, Pedal Left
128Contra Bombardon3235" windfrom Bombardon, Pedal Right
138Ophicleide16100" windfrom Grand Ophicleide, Pedal Right
1420Posaune1650" windfrom Major Posaune, Pedal Left
1518Bombard1650" windfrom Bombard, Pedal Left
167Bombardon1635" windfrom Bombardon, Pedal Right
178Ophicleide8100" windfrom Grand Ophicleide, Pedal Right
1820Posaune850" windfrom Major Posaune, Pedal Left
197Bombardon835" windfrom Bombardon, Pedal Right
2017Dulzian835" windfrom Dulzian, Pedal Right
2118Bombard450" windfrom Bombard, Pedal Left
2217Dulzian435" windfrom Dulzian, Pedal Right
23108Chimes8from Great-Solo, unenclosed
24BContra Drum StrikeFFfrom Percussion
25BContra Drum RollFFfrom Percussion
26CBass Drum StrikeFFfrom Percussion
27CBass Drum RollFFfrom Percussion
28DBass Drum StrikeFFfrom Percussion
29F,GSnare Drums RollFFfrom Percussion
30ESnare Drum StrikeFFfrom Percussion
31ESnare Drum RollFFfrom Percussion
32J,KPersian Cymbalsfrom Percussion
33HCymbalfrom Percussion
34Fanfare to Pedal8
35Gallery I to Pedal
36Gallery III to Pedal
37Brass Chorus to Pedal
38String I to Pedal
39String II to Pedal
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
UNENCLOSED CHOIR Manual 1Totals: 6 voices / 9 ranks / 657 pipes
1165Quintaton1631/2" windstraight73 pipes
2166Diapason831/2" windstraight73 pipes
3167Holz Flute831/2" windstraight73 pipes
4168Octave431/2" windstraight73 pipes
5169Fifteenth231/2" windstraight73 pipes
6170Rausch Quint 1215II31/2" windstraight146 pipes
7170Scharf Mixture 1922II31/2" windstraight146 pipes
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 7CHOIR Manual 1Totals: 29 voices / 37 ranks / 2,792 pipes
1171Contra Dulciana1610" windext. Dulciana
2176Contra Melodia1610" windext. Melodia
3172Diapason I810" windstraight73 pipes
4173Diapason II810" windstraight73 pipes
5171Dulciana810" windextended92 pipes
6174Dulciana Celeste810" windstraight73 pipes
7184Gemshorn810" windstraight73 pipes
8185Gemshorn Celeste810" windstraight73 pipes
9176Melodia810" windextended109 pipes
10177Philomela810" windstraight73 pipes
11178Concert Flute810" windstraight73 pipes
12179Unda Maris810" windstraight73 pipes
13309Nachthorn810" windstraight73 pipes
14186Viola Pomposa810" windstraight73 pipes
15187Viola Celeste810" windstraight73 pipes
16310Voix Celestes (2 ranks)810" windstraight134 pipes
17171Dulzquint51/310" windext. Dulciana
18175Dolce410" windextended97 pipes
19180Spindle Flute410" windstraight73 pipes
20181Flute Overte410" windstraight73 pipes
21309Fugara410" windstraight73 pipes
22175Dulzard Twelfth22/310" windext. Dolce
23176Melodia Twelfth22/310" windext. Melodia
24182Flageolet210" windstraight73 pipes
25175Dulcett Fifteenth210" windext. Dolce
26176Melodia Fifteenth210" windext. Melodia
27175Dulcett Nineteenth11/310" windext. Dolce
28175Dulcett Twenty-Second110" windext. Dolce
29183Flute Mixture 1519III10" windstraight219 pipes
30196Acuta 1931VI10" windstraight438 pipes
31188Contra Tromba1625" windextended97 pipes
32189Tromba Real825" windstraight73 pipes
33190Brass Cornet825" windstraight73 pipes
34191French Horn810" windstraight73 pipes
35192Clarinet810" windstraight73 pipes
36193Bassett Horn810" windstraight73 pipes
37194Cor Anglais810" windstraight73 pipes
38195Kinura810" windstraight73 pipes
39188Tromba Clarion425" windext. Contra Tromba
40Sub Octave16
41Octave4
42Great to Choir8
43Swell to Choir8
44Swell to Choir4
45Solo to Choir8
46Solo to Choir4
47Fanfare to Choir8
48Echo to Choir8
49Gallery I to Choir
50Gallery II to Choir
51Gallery III to Choir
52Gallery IV to Choir
53Brass Chorus to Choir
54String I to Choir
55String II to Choir
56String III to Choir
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
CHOIR-SWELL Manual 1
1147Gross Gedeckt1615" windfrom Swell-Choir
2311Stopped Diapason1610" windfrom Swell-Choir
3148Cone Gamba1615" windfrom Swell-Choir
4152Gemshorn815" windfrom Swell-Choir
5153Gemshorn Celeste I815" windfrom Swell-Choir
6154Gemshorn Celeste II815" windfrom Swell-Choir
7149Clarabella815" windfrom Swell-Choir
8150Doppel Spitz Flute810" windfrom Swell-Choir
9147Doppel Gedeckt815" windfrom Swell-Choir
10311Stopped Diapason810" windfrom Swell-Choir
11148Cone Gamba815" windfrom Swell-Choir
12155Third62/510" windfrom Swell-Choir
13156Fifth51/310" windfrom Swell-Choir
14156Gemshorn Quint51/315" windfrom Swell-Choir
15148Gamba Quint51/315" windfrom Swell-Choir
16157Seventh44/710" windfrom Swell-Choir
17152Octave Gemshorn415" windfrom Swell-Choir
18149Claribel Flute415" windfrom Swell-Choir
19150Spitz Flute410" windfrom Swell-Choir
20147Doppel Flute415" windfrom Swell-Choir
21311Stopped Flute410" windfrom Swell-Choir
22151Zauber Flute415" windfrom Swell-Choir
23148Cone Flute415" windfrom Swell-Choir
24158Ninth35/910" windfrom Swell-Choir
25155Major Tenth31/510" windfrom Swell-Choir
26154Gemshorn Tenth31/515" windfrom Swell-Choir
27159Eleventh210/1110" windfrom Swell-Choir
28153Gemshorn Twelfth22/315" windfrom Swell-Choir
29156Twelfth22/310" windfrom Swell-Choir
30149Flute Twelfth22/315" windfrom Swell-Choir
31311Stopped Flute Twelfth22/310" windfrom Swell-Choir
32157Octave Septieme22/710" windfrom Swell-Choir
33152Gemshorn Fifteenth215" windfrom Swell-Choir
34150Flute Fifteenth215" windfrom Swell-Choir
35151Magic Flute215" windfrom Swell-Choir
36158Sixteenth17/910" windfrom Swell-Choir
37155Major Seventeenth13/510" windfrom Swell-Choir
38154Gemshorn Seventeenth13/515" windfrom Swell-Choir
39159Eighteenth15/1110" windfrom Swell-Choir
40156Major Nineteenth11/310" windfrom Swell-Choir
41153Gemshorn Nineteenth11/315" windfrom Swell-Choir
42156Twenty-First11/710" windfrom Swell-Choir
43152Twenty-Second115" windfrom Swell-Choir
44151Zauber Twenty-Second115" windfrom Swell-Choir
45158Twenty-Third8/910" windfrom Swell-Choir
46155Twenty-Fourth4/510" windfrom Swell-Choir
47159Twenty-Fifth8/1110" windfrom Swell-Choir
48156Twenty-Sixth2/310" windfrom Swell-Choir
49152Twenty-Ninth1/215" windfrom Swell-Choir
50152Thirty-Sixth1/415" windfrom Swell-Choir
5119Fagotto3220" windfrom Fagotto, Pedal Left
52160Contra Oboe1615" windfrom Swell-Choir
53161Bass Clarinet1615" windfrom Swell-Choir
54162Bass Vox Humana1615" windfrom Swell-Choir
55160Oboe815" windfrom Swell-Choir
56161Clarinet815" windfrom Swell-Choir
57162Vox Humana815" windfrom Swell-Choir
58160Octave Oboe415" windfrom Swell-Choir
59161Octave Clarinet415" windfrom Swell-Choir
60162Vox Humana415" windfrom Swell-Choir
61108Chimes8from Great-Solo, unenclosed
62163Marimba Harp Repeat8from Swell-Choir
63163Marimba Harp Stroke8from Swell-Choir
64164Glockenspiel Repeat4from Swell-Choir
65164Glockenspiel Single4from Swell-Choir
66164Glockenspiel Single2from Swell-Choir
67F,GSnare Drums Rollfrom Percussion
68F,GSnare Drums Tapfrom Percussion
69ESnare Drum Rollfrom Percussion
70ESnare Drum Tapfrom Percussion
71PTom-Tomfrom Percussion
72OWood Blockfrom Percussion
73MCastinetsfrom Percussion
74NTrianglefrom Percussion
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
GRAND CHOIR Manual 1
111Diaphone1650" windfrom Diaphone, Pedal Left
211Diaphone Melody1650" windfrom Diaphone, Pedal Left
311Diaphone850" windfrom Diaphone, Pedal Left
412Diapason820" windfrom Diapason, Pedal Left
513Diaphonic Diapason835" windfrom Diaphonic Diapason, Pedal Left
615Tibia Clausa820" windfrom Tibia Clausa, Pedal Left
714Violoncello820" windfrom Bass Viol, Pedal Left
818Bombard1650" windfrom Bombard, Pedal Left
919Fagotto1620" windfrom Fagotto, Pedal Left
1020Major Posaune850" windfrom Major Posaune, Pedal Left
1118Bombard850" windfrom Bombard, Pedal Left
1218Bombard Melody450" windfrom Bombard, Pedal Left
1319Chalumeau820" windfrom Fagotto, Pedal Left
1419Octave Oboe420" windfrom Fagotto, Pedal Left
15Grand Choir On
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
CHOIR 2nd TOUCH Manual 1
1265Double Bass1615" windfrom Double Bass, String II
2266Contra Bass1615" windfrom Contra Bass, String II
3267Contra Viol1615" windfrom Contra Viol, String II
4265Viola815" windfrom Double Bass, String II
5266Violoncello815" windfrom Contra Bass, String II
6267Violoncello815" windfrom Contra Viol, String II
7266Violoncello415" windfrom Contra Bass, String II
8267Violoncello415" windfrom Contra Viol, String II
9Fanfare to Choir8
10Gallery I to Choir
11String I to Choir
12String II to Choir
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
GREAT Manual 2Totals: 38 voices / 63 ranks / 4,647 pipes
121Sub Principal3220" windextended121 pipes
222Double Diapason I1620" windextended97 pipes
323Double Diapason II1615" windstraight73 pipes
424Double Diapason III1610" windstraight73 pipes
525Sub Quint102/315" windstraight73 pipes
626Diapason I830" windstraight73 pipes
727Diapason II830" windstraight73 pipes
828Diapason III820" windstraight73 pipes
921Principal820" windext. Sub Principal
1029Diapason IV815" windstraight73 pipes
1130Diapason V815" windstraight73 pipes
1231Diapason VI815" windstraight73 pipes
1332Diapason VII810" windstraight73 pipes
1433Diapason VIII810" windstraight73 pipes
1534Diapason IX810" windstraight73 pipes
1635Diapason X84" windstraight73 pipes
1753Harmonic Flute815" windstraight73 pipes
1854Flute Overte84" windstraight73 pipes
1936Quint51/320" windstraight73 pipes
2037Octave I420" windstraight73 pipes
2138Octave II420" windstraight73 pipes
2222Octave Diapason420" windext. Double Diapason I
2339Octave III415" windstraight73 pipes
2440Octave IV410" windstraight73 pipes
2541Octave V410" windstraight73 pipes
2655Harmonic Flute415" windstraight73 pipes
2742Gross Tierce31/520" windstraight73 pipes
2842Major Twelfth22/320" windstraight73 pipes
2944Fifteenth I220" windstraight73 pipes
3021Super Principal220" windext. Sub Principal
3145Fifteenth II215" windstraight73 pipes
3246Fifteenth III210" windstraight73 pipes
3347Rausch Quint 58II30" windstraight146 pipes
3448Rausch Quint 1215II30" windstraight146 pipes
3549Grand Cornet 0522XI20" windstraight803 pipes
3649Major Sesquialtera 1022V20" windstraight365 pipes
3751Schulze Mixture 1226V4" windstraight365 pipes
3852Furniture 1736VI15" windstraight414 pipes
3949Scharf Mixture 1722III20" windfrom Grand Cornet
4051Doublette Mixture 2226II4" windfrom Schulze Mixture
4156Trumpet1630" windstraight73 pipes
4256Harmonic Trumpet830" windstraight73 pipes
4356Harmonic Clarion430" windstraight73 pipes
44108Chimes8from Great-Solo, unenclosed
45107Harp8from Great-Solo, unenclosed
46107Harp4from Great-Solo, unenclosed
4794Xylophone4from Great-Solo, unenclosed
4894Xylophone2from Great-Solo, unenclosed
49F,GSnare Drums Rollfrom Percussion
50F,GSnare Drums Tapfrom Percussion
51ESnare Drum Rollfrom Percussion
52ESnare Drum Tapfrom Percussion
53PTom-Tomfrom Percussion
54OWood Block Rollfrom Percussion
55OWood Block Strokefrom Percussion
56MCastinetsfrom Percussion
57LTambourinefrom Percussion
58NTrianglefrom Percussion
59Choir to Great16
60Choir to Great8
61Choir to Great4
62Swell to Great16
63Swell to Great8
64Swell to Great4
65Solo to Great8
66Solo to Great4
67Fanfare to Great8
68Fanfare to Great4
69Echo to Great16
70Echo to Great8
71Echo to Great4
72Gallery I to Great
73Gallery II to Great
74Gallery III to Great
75Gallery IV to Great
76Brass Chorus to Great
77String I to Great
78String II to Great
79String III to Great
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 2GREAT-SOLO Manual 2Totals: 13 voices / 13 ranks / 1,152 pipes
182Geigen Principal1615" windext. Geigen Principal
281Wald Flute1615" windext. Wald Flute
383Tibia Clausa1615" windext. Tibia Clausa
481Wald Quint102/315" windext. Wald Flute
583Tibia Quint102/315" windext. Tibia Clausa
684Diapason Phonon815" windextended73 pipes
785Horn Diapason815" windextended85 pipes
882Geigen Principal815" windextended97 pipes
987Gemshorn815" windextended121 pipes
1088Gemshorn Celeste815" windextended89 pipes
1181Wald Flute815" windextended97 pipes
1286Doppel Gedeckt815" windextended73 pipes
1387Tibia Clausa815" windextended92 pipes
1489Viola d'Gamba815" windextended73 pipes
1590Vox Celeste815" windextended73 pipes
1691Gemshorn Terz62/515" windextended97 pipes
1791Gemshorn Quint51/315" windextended97 pipes
1881Wald Quint51/315" windext. Wald Flute
1993Gemshorn Septieme44/715" windextended85 pipes
2084Octave Phonon415" windext. Diapason Phonon
2185Octave415" windext. Horn Diapason
2282Geigen Principal415" windext. Geigen Principal
2387Gemshorn415" windext. Gemshorn
2488Gemshorn Celeste415" windext. Gemshorn Celeste
2581Wald Flute415" windext. Wald Flute
2686Doppel Gedeckt415" windext. Doppel Gedeckt
2783Tibia Clausa415" windext. Tibia Clausa
2889Viola d'Gamba415" windext. Viola d'Gamba
2987Vox Celeste415" windext. Vox Celeste
3088Gemshorn Tenth31/515" windext. Gemshorn Celeste
3191Tenth31/515" windext. Gemshorn Terz
3292Twelfth22/315" windext. Gemshorn Quint
3381Flute Twelfth22/315" windext. Wald Flute
3481Minor Twelfth22/315" windext. Tibia Clausa
3593Octave Septieme22/715" windext. Gemshorn Septieme
3685Fifteenth215" windext. Horn Diapason
3782Geigen Fifteenth215" windext. Geigen Principal
3887Gemshorn Fifteenth215" windext. Gemshorn
3981Piccolo215" windext. Wald Flute
4088Gemshorn Seventeenth13/515" windext. Gemshorn Celeste
4191Seventeenth13/515" windext. Gemshorn Terz
4292Nineteenth11/315" windext. Gemshorn Quint
4393Twenty-First11/715" windext. Gemshorn Septieme
4487Gemshorn115" windext. Gemshorn
4591Twenty-Fourth4/515" windext. Gemshorn Terz
4692Twenty-Sixth2/315" windext. Gemshorn Quint
4787Twenty-Ninth1/215" windext. Gemshorn
4887Thirty-Sixth1/415" windext. Gemshorn
Swell Box 3GREAT-SOLO Manual 2Totals: 12 voices / 12 ranks / 972 pipes
4996Saxophone1615" windext. Saxophone
5098French Horn1615" windext. French Horn
5197English Horn1615" windext. English Horn
5295Oboe-Horn1615" windext. Oboe-Horn
53100Krummhorn1615" windext. Krummhorn
5499Vox Baryton1615" windextended85 pipes
55102Orchestral Saxophone815" windstraight73 pipes
5696Saxophone815" windextended97 pipes
57101Clarinet815" windstraight73 pipes
5898French Horn815" windextended85 pipes
5997English Horn815" windextended97 pipes
6095Oboe-Horn815" windextended97 pipes
61103Orchestral Oboe815" windstraight73 pipes
62100Krummhorn815" windextended85 pipes
63105Vox Humana815" windstraight73 pipes
6499Vox Humana815" windext. Vox Baryton
65106Kinura815" windstraight73 pipes
6696Saxophone415" windext. Saxophone
6798French Horn415" windext. French Horn
6897English Horn415" windext. English Horn
6995Oboe-Horn415" windext. Oboe-Horn
70100Krummhorn415" windext. Krummhorn
7199Vox Baryton415" windext. Vox Baryton
7264Flute Twelfth22/315" windstraight (originally on Solo)61 pipes
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
GRAND GREAT Manual 2
14Principal830" windfrom Principal, Pedal Right
23Tibia Major830" windfrom Tibia Major, Pedal Right
31Tibia Clausa820" windfrom Tibia Clausa, Pedal Right
43Tibia Melody430" windfrom Tibia Major, Pedal Right
55Viol830" windfrom Viol, Pedal Right
65Viol Melody430" windfrom Viol, Pedal Right
721Octave420" windfrom Sub Principal, Great
84Super Octave230" windfrom Principal, Pedal Right
917Dulzian3235" windfrom Dulzian, Pedal Right
108Trombone1635" windfrom Bombardon, Pedal Right
118Trombone Melody835" windfrom Bombardon, Pedal Right
129Ophicleide8100" windfrom Grand Ophicleide, Pedal Right
1310Trumpet820" windfrom Trumpet, Pedal Right
1410Clarion420" windfrom Trumpet, Pedal Right
1510Clarion Melody420" windfrom Trumpet, Pedal Right
16Grand Great On
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
GREAT 2nd TOUCH Manual 2
1254Viol Phonon825" windfrom Contra Basso, String I
2265Violoncello815" windfrom Double Bass, String II
3266Viol815" windfrom Contra Bass, String II
4267Viol815" windfrom Contra Viol, String II
5108Chimes8from Great-Solo, unenclosed
6E,F,GMuffled Drumsfrom Percussion
7Solo to Great8
8Solo to Great4
9Fanfare to Great8
10Gallery I to Great
11Brass Chorus to Great
12String I to Great
13String II to Great
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 5SWELL Manual 3Totals: 36 voices / 55 ranks / 4,456 pipes
1117Double Diapason1615" windextended104 pipes
2131Contra Gamba1615" windextended104 pipes
3118Diapason I815" windstraight80 pipes
4119Diapason II815" windstraight80 pipes
5120Waldhorn815" windstraight80 pipes
6124Tibia Plena815" windstraight80 pipes
7125Hohl Flute815" windstraight80 pipes
8127Harmonic Flute815" windstraight80 pipes
9312Harmonic Flute Celeste815" windstraight80 pipes
10126Gross Gedeckt815" windstraight80 pipes
11135Gamba815" windstraight80 pipes
12136Gamba Celeste815" windstraight80 pipes
13132Violin815" windstraight80 pipes
14133Viol Celestes I (2 ranks)815" windstraight134 pipes
15134Viol Celestes II (2 ranks)815" windstraight146 pipes
16128Ocarina415" windstraight80 pipes
17121Octave I415" windstraight80 pipes
18117Octave II415" windext. Double Diapason
19129Traverse Flute415" windstraight80 pipes
20313Silver Flute415" windstraight80 pipes
21137Gambette415" windstraight80 pipes
22131Salicet415" windext. Contra Gamba
23122Fifteenth215" windstraight80 pipes
24130Orchestral Piccolo215" windstraight80 pipes
25317Cymbale 1226VIII15" windstraight640 pipes
26123Furniture 1529V15" windstraight400 pipes
27146Plein Jeu 1536VII15" windstraight560 pipes
28138Double Trumpet1630" windextended104 pipes
29142Double Horn1615" windextended104 pipes
30139Harmonic Trumpet830" windstraight80 pipes
31140Field Trumpet830" windstraight80 pipes
32143Posaune815" windstraight80 pipes
33144Cornopean815" windstraight80 pipes
34314Muted Trumpet815" windstraight80 pipes
35145Flugel Horn815" windstraight80 pipes
36315Krummhorn815" windstraight80 pipes
37316Vox Humana815" windstraight80 pipes
38141Trumpet Clarion430" windstraight80 pipes
39138Trumpet Clarion415" windext. Double Trumpet
40142Octave Horn415" windext. Double Horn
41Sub Octave16
42Octave4
43Choir to Swell16
44Choir to Swell8
45Choir to Swell4
46Solo to Swell16
47Solo to Swell8
48Solo to Swell4
49Fanfare to Swell8
50Fanfare to Swell4
51Echo to Swell16
52Echo to Swell8
53Echo to Swell4
54Gallery I to Swell
55Gallery II to Swell
56Gallery III to Swell
57Gallery IV to Swell
58Brass Chorus to Swell
59String I to Swell
60String II to Swell
61String III to Swell
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 6SWELL-CHOIR Manual 3Totals: 17 voices / 17 ranks / 1,542 pipes
1147Gross Gedeckt1615" windext. Gross Gedeckt
2311Stopped Diapason1610" windext. Stopped Diapason
3148Cone Gamba1615" windext. Cone Gamba
4152Gemshorn815" windextended121 pipes
5153Gemshorn Celeste I815" windextended92 pipes
6154Gemshorn Celeste II815" windextended89 pipes
7149Clarabella815" windextended80 pipes
8150Doppel Spitz Flute810" windextended85 pipes
9147Doppel Gedeckt815" windextended97 pipes
10311Stopped Diapason810" windextended92 pipes
11148Cone Gamba815" windextended85 pipes
12155Third62/510" windextended97 pipes
13156Fifth51/310" windextended109 pipes
14156Gemshorn Quint51/315" windext. Gemshorn Celeste I
15148Gamba Quint51/315" windext. Cone Gamba
16157Seventh44/710" windextended85 pipes
17152Octave Gemshorn415" windext. Gemshorn
18149Claribel Flute415" windext. Clarabella
19150Spitz Flute410" windext. Doppel Spitz Flute
20147Doppel Flute415" windext. Doppel Gedeckt
21311Stopped Flute410" windext. Stopped Diapason
22151Zauber Flute415" windextended85 pipes
23148Cone Flute415" windext. Cone Gamba
24158Ninth35/910" windextended85 pipes
25155Major Tenth31/510" windext. Third
26154Gemshorn Tenth31/515" windext. Gemshorn Celeste II
27159Eleventh210/1110" windextended85 pipes
28153Gemshorn Twelfth22/315" windext. Gemshorn Celeste I
29156Twelfth22/310" windext. Fifth
30149Flute Twelfth22/315" windext. Clarabella
31311Stopped Flute Twelfth22/310" windext. Stopped Diapason
32157Octave Septieme22/710" windext. Seventh
33152Gemshorn Fifteenth215" windext. Gemshorn
34147Gedeckt Fifteenth215" windext. Doppel Gedeckt
35151Magic Flute215" windext. Zauber Flute
36158Sixteenth17/910" windext. Ninth
37155Major Seventeenth13/510" windext. Third
38154Gemshorn Seventeenth13/515" windext. Gemshorn Celeste II
39159Eighteenth15/1110" windext. Eleventh
40156Major Nineteenth11/310" windext. Fifth
41153Gemshorn Nineteenth11/315" windext. Gemshorn Celeste I
42156Twenty-First11/710" windext. Seventh
43152Twenty-Second115" windext. Gemshorn
44151Zauber Twenty-Second115" windext. Zauber Flute
45158Twenty-Third8/910" windext. Ninth
46155Twenty-Fourth4/510" windext. Third
47159Twenty-Fifth8/1110" windext. Eleventh
48156Twenty-Sixth2/310" windext. Fifth
49152Twenty-Ninth1/215" windext. Gemshorn
50156Thirty-Third1/310" windext. Fifth
51152Thirty-Sixth1/415" windext. Gemshorn
5219Fagotto3220" windfrom Fagotto, Pedal Left
53160Contra Oboe1615" windext. Oboe
54161Bass Clarinet1615" windext. Clarinet
55162Bass Vox Humana1615" windext. Vox Humana
56160Oboe815" windextended85 pipes
57161Clarinet815" windextended85 pipes
58162Vox Humana815" windextended85 pipes
59160Octave Oboe415" windext. Oboe
60161Octave Clarinet415" windext. Clarinet
61162Vox Humana415" windext. Vox Humana
62163Marimba Harp Repeat8from Marimba Harp
63163Marimba Harp Stroke8from Marimba Harp
64163Marimba Harp Repeat4from Marimba Harp
65163Marimba Harp Stroke4from Marimba Harp
66164Glockenspiel Repeat4from Glockenspiel
67164Glockenspiel Single4from Glockenspiel
68164Glockenspiel Single2from Glockenspiel
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 1SOLO Manual 4Totals: 22 voices / 33 ranks / 2,085 pipes
159Major Flute1630" windext. Major Flute
259Flute Quint102/330" windext. Major Flute
371Stentor Diapason830" windstraight61 pipes
479Diapason830" wind8' rank from Grand Chorus
560Tibia Rex830" windstraight61 pipes
659Major Flute830" windextended85 pipes
761Hohl Flute820" windstraight61 pipes
862Flute Overte820" windstraight61 pipes
966Cello Pomposa820" windstraight61 pipes
1067Cello Celeste820" windstraight61 pipes
1168Violin820" windstraight61 pipes
1269Violin Celeste820" windstraight61 pipes
1359Flute Quint51/330" windext. Major Flute
1472Stentor Octave430" windstraight61 pipes
1579Octave430" wind4' rank from Grand Chorus
1659Major Flute430" windext. Major Flute
1763Wald Flute430" windstraight61 pipes
1870Viola Pomposa420" windstraight61 pipes
1965Harmonic Piccolo220" windstraight61 pipes
2079Grand Chorus 129IX30" windstraight549 pipes
2180Carillon 1724IV30" windstraight244 pipes
2273Tuba Magna1650" windext. Tuba Magna
2374Trumpet Profunda1630" windext. Trumpet Profunda
2474Trumpet Quint102/330" windext. Trumpet Profunda
2575Tuba Imperial8100" windstraight61 pipes
2673Tuba Magna850" windextended85 pipes
2778Bugle850" windstraight61 pipes
2876Trumpet Royal830" windstraight61 pipes
2974Trumpet Profunda830" windextended85 pipes
3077English (Post) Horn830" windstraight61 pipes
31104French Horn820" windstraight (originally on Great-Solo)61 pipes
3273Magna Fifth51/350" windext. Tuba Magna
3373Tuba Clarion450" windext. Tuba Magna
3474Trumpet Clarion430" windext. Trumpet Profunda
35Sub Octave16
36Octave4
37Choir to Solo8
38Great to Solo8
39Fanfare to Solo8
40Fanfare to Solo4
41Echo to Solo8
42Gallery I to Solo
43Gallery II to Solo
44Gallery III to Solo
45Gallery IV to Solo
46Brass Chorus to Solo
47String I to Solo
48String II to Solo
49String III to Solo
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
SOLO-GREAT Manual 4
182Geigen Principal1615" windfrom Great-Solo
281Wald Flute1615" windfrom Great-Solo
383Tibia Clausa1615" windfrom Great-Solo
481Wald Quint102/315" windfrom Great-Solo
583Tibia Quint102/315" windfrom Great-Solo
684Diapason Phonon815" windfrom Great-Solo
785Horn Diapason815" windfrom Great-Solo
882Geigen Principal815" windfrom Great-Solo
987Gemshorn815" windfrom Great-Solo
1088Gemshorn Celeste815" windfrom Great-Solo
1181Wald Flute815" windfrom Great-Solo
1286Doppel Gedeckt815" windfrom Great-Solo
1387Tibia Clausa815" windfrom Great-Solo
1489Viola d'Gamba815" windfrom Great-Solo
1590Vox Celeste815" windfrom Great-Solo
1691Gemshorn Terz62/515" windfrom Great-Solo
1791Gemshorn Quint51/315" windfrom Great-Solo
1881Wald Quint51/315" windfrom Great-Solo
1993Gemshorn Septieme44/715" windfrom Great-Solo
2084Octave Phonon415" windfrom Great-Solo
2185Octave415" windfrom Great-Solo
2282Geigen Principal415" windfrom Great-Solo
2387Gemshorn415" windfrom Great-Solo
2488Gemshorn Celeste415" windfrom Great-Solo
2581Wald Flute415" windfrom Great-Solo
2686Doppel Gedeckt415" windfrom Great-Solo
2783Tibia Clausa415" windfrom Great-Solo
2889Viola d'Gamba415" windfrom Great-Solo
2987Vox Celeste415" windfrom Great-Solo
3088Gemshorn Tenth31/515" windfrom Great-Solo
3191Tenth31/515" windfrom Great-Solo
3292Twelfth22/315" windfrom Great-Solo
3381Flute Twelfth22/315" windfrom Great-Solo
3481Minor Twelfth22/315" windfrom Great-Solo
3593Octave Septieme22/715" windfrom Great-Solo
3685Fifteenth215" windfrom Great-Solo
3782Geigen Fifteenth215" windfrom Great-Solo
3887Gemshorn Fifteenth215" windfrom Great-Solo
3981Piccolo215" windfrom Great-Solo
4088Gemshorn Seventeenth13/515" windfrom Great-Solo
4191Seventeenth13/515" windfrom Great-Solo
4292Nineteenth11/315" windfrom Great-Solo
4393Twenty-First11/715" windfrom Great-Solo
4487Gemshorn115" windfrom Great-Solo
4591Twenty-Fourth4/515" windfrom Great-Solo
4692Twenty-Sixth2/315" windfrom Great-Solo
4787Twenty-Ninth1/215" windfrom Great-Solo
4887Thirty-Sixth1/415" windfrom Great-Solo
4996Saxophone1615" windfrom Great-Solo
5098French Horn1615" windfrom Great-Solo
5197English Horn1615" windfrom Great-Solo
5295Oboe-Horn1615" windfrom Great-Solo
53100Krummhorn1615" windfrom Great-Solo
5499Vox Baryton1615" windfrom Great-Solo
55102Orchestral Saxophone815" windfrom Great-Solo
5696Saxophone815" windfrom Great-Solo
57101Clarinet815" windfrom Great-Solo
5898French Horn815" windfrom Great-Solo
5997English Horn815" windfrom Great-Solo
6095Oboe-Horn815" windfrom Great-Solo
61103Orchestral Oboe815" windfrom Great-Solo
62100Krummhorn815" windfrom Great-Solo
63105Vox Humana815" windfrom Great-Solo
6499Vox Humana815" windfrom Great-Solo
65106Kinura815" windfrom Great-Solo
6696Saxophone415" windfrom Great-Solo
6798French Horn415" windfrom Great-Solo
6897English Horn415" windfrom Great-Solo
6995Oboe-Horn415" windfrom Great-Solo
70100Krummhorn415" windfrom Great-Solo
7199Vox Baryton415" windfrom Great-Solo
7264Flute Twelfth22/315" windfrom Great-Solo
73108Chimes8from Great-Solo, unenclosed
74107Harp8from Great-Solo, unenclosed
75107Harp4from Great-Solo, unenclosed
7694Xylophone4from Great-Solo, unenclosed
7794Xylophone2from Great-Solo, unenclosed
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 9FANFARE Manual 5Totals: 21 voices / 36 ranks / 2,364 pipes
1197Major Flute1620" windextended85 pipes
2212Stentor Diapason835" wind8' rank from Stentor Mixture
3199Stentorphone820" windstraight61 pipes
4198Stentor Flute835" windstraight61 pipes
5199Pileata Magna820" windstraight61 pipes
6304Gamba Tuba820" windstraight61 pipes
7305Gamba Tuba Celeste820" windstraight61 pipes
8212Stentor Octave435" wind4' rank from Stentor Mixture
9197Major Flute420" windext. Major Flute
10201Flute Octaviante420" windstraight61 pipes
11306Gamba Clarion420" windstraight61 pipes
12202Recorder Twelfth22/320" windstraight61 pipes
13203Fife220" windstraight61 pipes
14212Stentor Mixture 122VII35" windstraight427 pipes
15307Harmonic Mixture 1729VI20" windstraight366 pipes
16204Cymbale 1933V20" windstraight305 pipes
17205Contra Posaune1650" windext. Posaune
18206Contra Bombardon1635" windext. Bombardon
19299Contra Trombone1635" windext. Trombone
20209Tromba Quint102/320" windextended85 pipes
21207Harmonic Tuba850" windextended73 pipes
22207Tuba Melody450" windfrom Harmonic Tuba
23208Ophicleide850" windstraight61 pipes
24205Posaune850" windextended85 pipes
25206Bombardon835" windextended97 pipes
26299Trombone835" windextended97 pipes
27209Tromba820" windext. Tromba Quint
28210Tromba Tierce62/520" windextended73 pipes
29299Trombone Fifth51/335" windext. Trombone
30209Tromba Fifth51/320" windext. Tromba Quint
31211Major Clarion450" windstraight61 pipes
32207Harmonic Clarion450" windext. Harmonic Tuba
33206Octave Posaune450" windext. Posaune
34206Bombardon435" windext. Bombardon
35299Trombone Clarion435" windext. Trombone
36210Tromba Tierce31/520" windext. Tromba Tierce
37209Tromba Twelfth22/320" windext. Tromba Quint
38206Clarine Fifteenth235" windext. Bombardon
39Choir to Fanfare16
40Choir to Fanfare8
41Choir to Fanfare4
42Great to Fanfare8
43Swell to Fanfare16
44Swell to Fanfare8
45Swell to Fanfare4
46Solo to Fanfare8
47Echo to Fanfare8
48Gallery I to Fanfare
49Gallery II to Fanfare
50Gallery III to Fanfare
51Gallery IV to Fanfare
52String I to Fanfare
53String II to Fanfare
54String III to Fanfare
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 8ECHO Manual 6Totals: 22 voices / 27 ranks / 1,898 pipes
1214Spire Flute1615" windext. Spire Flute
2298Contra Violone1625" windext. Violone
3213Contra Gamba1615" windext. Gamba
4215Diapason815" windstraight61 pipes
5219Waldhorn815" windstraight61 pipes
6220Clarabella815" windextended97 pipes
7214Spire Flute815" windextended109 pipes
8216Spitz Flute815" windstraight61 pipes
9217Spitz Flute Celeste I815" windstraight61 pipes
10218Spitz Flute Celeste II815" windextended77 pipes
11222Flute Sylvestre815" windstraight61 pipes
12223Flute Celeste815" windstraight61 pipes
13221Tibia Mollis815" windstraight61 pipes
14298Violone825" windextended97 pipes
15319Violone Celeste825" windstraight56 pipes
16213Gamba815" windextended85 pipes
17220Open Flute415" windext. Clarabella
18224Rohr Flute415" windstraight61 pipes
19214Spire Flute415" windext. Spire Flute
20298Violone425" windext. Violone
21213Gamba415" windext. Gamba
22218Spitz Tenth31/515" windext. Spitz Flute Celeste II
23220Open Flute22/315" windext. Clarabella
24214Spire Flute22/315" windext. Spire Flute
25220Flute Fifteenth215" windext. Clarabella
26214Spire Flute215" windext. Spire Flute
27218Spitz Seventeenth13/515" windext. Spitz Flute Celeste II
28214Spire Flute11/315" windext. Spire Flute
29214Spire Flute115" windext. Spire Flute
30225Mixture Aetheria 1529VI15" windstraight366 pipes
31231Tuba d'Amour1625" windext. Tuba d'Amour
32226Contra Bassoon1615" windext. Bassoon
33226Chalumeau1615" windext. Clarinet
34230Vox Humana1615" windext. Vox Humana II
35231Tuba d'Amour825" windextended85 pipes
36228Trumpet Minor815" windstraight61 pipes
37229Cor d'Amour815" windstraight61 pipes
38226Bassoon815" windextended85 pipes
39226Clarinet815" windextended85 pipes
40303Vox Humana I815" windstraight61 pipes
41230Vox Humana II815" windextended85 pipes
42231Tuba d'Amour425" windext. Tuba d'Amour
43226Octave Bassoon415" windext. Bassoon
44226Octave Clarinet415" windext. Clarinet
45230Vox Humana415" windext. Vox Humana II
46232Chimes8
47Sub Octave16
48Octave4
49Choir to Echo8
50Great to Echo8
51Solo to Echo8
52Fanfare to Echo8
53Gallery I to Echo
54Gallery II to Echo
55Gallery III to Echo
56Gallery IV to Echo
57String I to Echo
58String II to Echo
59String III to Echo
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
BOMBARD Manual 7
1Gallery I to Bombard
2Gallery II to Bombard
3Gallery III to Bombard
4Gallery IV to Bombard
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
GALLERY I FloatingTotals: 4 voices / 10 ranks / 754 pipes
1233Contra Diaphone1625" windextended85 pipes
2233Diaphone825" windext. Contra Diaphone
3318Diapason825" wind8' rank from Mixture Mirabilis
4318Octave825" wind4' rank from Mixture Mirabilis
5318Mixture Mirabilis 122VII25" windstraight511 pipes
6235Trumpet Mirabilis16100" windextended85 pipes
7235Trumpet Melody16100" windfrom Trumpet Mirabilis
8234Tuba Maxima8100" windextended73 pipes
9235Trumpet Imperial8100" windext. Trumpet Mirabilis
10234Clarion Mirabilis4100" windext. Tuba Maxima
11234Clarion Melody4100" windext. Tuba Maxima
12235Clarion Real4100" windext. Trumpet Mirabilis
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 11GALLERY II FloatingTotals: 7 voices / 9 ranks / 621 pipes
1242Flauto Maggiore1625" windextended97 pipes
2243Jubal Flute825" windstraight73 pipes
3243Flute Melody425" windfrom Jubal Flute
4244Harmonic Flute825" windstraight73 pipes
5244Harmonic Flute425" windstraight73 pipes
6242Flute Melodic425" windext. Flauto Maggiore
7246Harmonic Twelfth22/325" windstraight61 pipes
8247Harmonic Piccolo225" windstraight61 pipes
9248Harmonic Mixture 1722III25" windstraight183 pipes
10Sub Octave16
11Octave4
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
GALLERY III FloatingTotals: 6 voices / 9 ranks / 681 pipes
1236Contra Diapason1620" windextended97 pipes
2237Diapason I820" windstraight73 pipes
3238Diapason II820" windstraight73 pipes
4239Octave I420" windstraight73 pipes
5236Octave II420" windext. Contra Diapason
6240Fifteenth220" windstraight73 pipes
7241Mixture 1222IV20" windstraight292 pipes
8AGrand Piano16from Grand Piano, in Left Center Chamber
9AGrand Piano8from Grand Piano, in Left Center Chamber
10AGrand Piano4from Grand Piano, in Left Center Chamber
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 12GALLERY IV FloatingTotals: 8 voices / 8 ranks / 596 pipes
1249Contra Saxophone1625" windext. Saxophone
2300Brass Trumpet825" windstraight73 pipes
3302Egyptian Horn825" windstraight73 pipes
4301Euphone825" windstraight73 pipes
5253Major Clarinet825" windstraight73 pipes
6250Major Oboe825" windstraight73 pipes
7251Musette Mirabilis825" windstraight73 pipes
8252Cor d'Orchestre825" windstraight73 pipes
9249Saxophone825" windextended85 pipes
10249Octave Saxophone425" windext. Saxophone
11Sub Octave16
12Octave4
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 4BRASS CHORUS FloatingTotals: 8 voices / 10 ranks / 730 pipes
1110Trombone1625" windstraight73 pipes
2111Trombone I825" windstraight73 pipes
3112Trombone II825" windstraight73 pipes
4113Tromba Quint51/320" windstraight73 pipes
5114Trombone425" windstraight73 pipes
6115Tromba Twelfth22/320" windstraight73 pipes
7116Trombone225" windstraight73 pipes
8117Tierce Mixture 1022III20" windstraight183 pipes
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 13STRING I FloatingTotals: 11 voices / 20 ranks / 1,436 pipes
1254Contra Basso1625" windextended97 pipes
2255Cello825" windstraight73 pipes
3256Cello Celestes I (2 ranks)825" windstraight146 pipes
4257Cello Celestes II (2 ranks)825" windstraight134 pipes
5258Violins I (2 ranks)825" windstraight146 pipes
6259Violins II (2 ranks)825" windstraight134 pipes
7260Violins III (2 ranks)825" windstraight146 pipes
8261Violins IV (2 ranks)825" windstraight134 pipes
9262Violins Secundo I (2 ranks)825" windstraight146 pipes
10263Violins Secundo II (2 ranks)825" windstraight134 pipes
11254Octave Viola425" windext. Contra Basso
12264Violins Secundo (2 ranks)425" windstraight146 pipes
13Sub Octave16
14Octave4
15Melody16
16Melody4
17Pizzicato
18Separation
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 14STRING II FloatingTotals: 24 voices / 37 ranks / 2,658 pipes
1265Double Bass1615" windextended97 pipes
2266Contra Bass1615" windextended97 pipes
3267Contra Viol1615" windextended97 pipes
4268Viola Diapason815" windstraight73 pipes
5269Violincello815" windstraight73 pipes
6270Cello Phonon815" windstraight73 pipes
7271Cello815" windstraight73 pipes
8272Cello Celestes (2 ranks)815" windstraight146 pipes
9273Viola Phonon815" windstraight73 pipes
10274Viola Celestes (2 ranks)815" windstraight134 pipes
11275Violin Phonon815" windstraight73 pipes
12276Viol815" windstraight73 pipes
13277Viol Celestes I (2 ranks)815" windstraight146 pipes
14278Viol Celestes II (2 ranks)815" windstraight134 pipes
15279Viol Celestes III (2 ranks)815" windstraight134 pipes
16280Viol Celestes IV (2 ranks)815" windstraight134 pipes
17281Viol Celestes V (2 ranks)815" windstraight134 pipes
18287Flute Quint51/315" windext. Stopped Flute
19284Viol Principal415" windstraight73 pipes
20265Octave Cello I415" windext. Double Bass
21266Octave Cello II415" windext. Contra Bass
22267Octave Violin415" windext. Contra Viol
23282Violins (2 ranks)415" windstraight146 pipes
24283Violas (2 ranks)415" windstraight146 pipes
25287Stopped Flute415" windextended78 pipes
26288Flute Twelfth22/315" windstraight73 pipes
27287Piccolo215" windext. Stopped Flute
28285String Mixture 1022V15" windstraight305 pipes
29286Tromba d'Amour815" windstraight73 pipes
30Sub Octave16
31Octave4
32Melody16
33Melody4
34Pizzicato
35Separation
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Swell Box 9STRING III FloatingTotals: 9 voices / 17 ranks / 1,217 pipes
1289Cello Celestes I (2 ranks)815" windstraight146 pipes
2290Cello Celestes II (2 ranks)815" windstraight146 pipes
3291Viola Celestes (2 ranks)815" windstraight146 pipes
4292Viol Celestes I (2 ranks)815" windstraight146 pipes
5293Viol Celestes II (2 ranks)815" windstraight134 pipes
6294Viol Celestes III (2 ranks)815" windstraight146 pipes
7295Viol Celestes IV (2 ranks)815" windstraight134 pipes
8296Viol Celestes V (2 ranks)815" windstraight146 pipes
9297Cor Anglais815" windstraight73 pipes
10Sub Octave16
11Octave4
12AGrand Piano16from Grand Piano, in Left Center Chamber
13AGrand Piano8from Grand Piano, in Left Center Chamber
14AGrand Piano4from Grand Piano, in Left Center Chamber
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
1Master Tremolo
TREMOLOS RIGHT
2Great Tibia
3Great-Solo Flues
4Great-Solo Reeds
5Solo Low Pressure (20")
6Echo
7String II
TREMOLOS LEFT
8Unenclosed Choir
9Choir
10Choir Philomela
11Swell
12Swell-Choir
13Swell-Choir Vox Humana
14Fanfare
15Fanfare Pileata Magna
16Gallery IV
17String I
18String III
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
Note 1: Dulzian 64 / Diaphone 64
The 64-foot stop is a reed, with 85 pipes in its rank. It has diaphone pipes for its lowest 22 notes, from (32-foot) AAAA down to CCCCC. Despite this, it remains a reed stop in the same way that a 4-foot Clarion remains a reed, even if its uppermost notes consist of flue pipes, and a Clarabella is classified as an open flute, even if its bass is stopped. The change-over from reed pipes to diaphones is undetectable.

The instrument's original scheme specified two 64-foot stops, i.e. a Diaphone (to have been stop number 1) in the Pedal Right and a Dulzian in the Pedal Left. However, the Diaphone was deleted when the scheme was revised. The Pedal Left's Dulzian was retained but it was later moved to the other side. This is why the Pedal Right (which has stops numbered from from 1 to 10) also includes stop number 17, i.e. the Dulzian from the Pedal Left (stops 11 to 20). However, this still begs the question: Why are there 64-foot Diaphone stop-keys on the console? The answer is simple: After the original Diaphone was deleted, there was some experimentation to see if diaphone and reed tone could be produced from a dual mechanism fitted to a single pipe. The device wasn't a success and the idea was abandoned but the stop-keys were already on the console (incidentally, they all bear the number 17, which is the Dulzian's number).

The main reason why the 64-foot "Diaphone" at Atlantic City is somewhat entrenched in the organ world's psyche is because it's usually the first thing people see when they look at the stop list which, as here, invariably starts with the Pedal Right's registers. By the time they get to "Dulzian 64", many have largely given-up reading it properly.

Dulzian is a curious choice of name for this stop. It's certainly not the light-toned voice that we associate, these days, with ranks of that name. Richards described the stop, in the contract, as of "Tromba quality", and the blocks of its treble pipes are stamped "Posaune". So, it's obviously a chorus reed. One has to wonder if Richards was running out of stop names for the instrument and had seen this somewhere perhaps on one of his trips to Germany? and thought "I'll use that"!

Note 2: Pipe Numbers
Although there are tales of stops/ranks being left out of the organ, they're untrue. Everything is present, all 449 ranks and 337 stops (314 voices and 23 percussions seven melodic, 16 non-melodic). The official total number of pipes is 33,112 but the actual number is unknown. I have comprehensively surveyed the instrument and investigated all the available evidence about pipe numbers. I concluded that the figure was 33,114 but this is unlikely to be 100% accurate and I've recently revised it to 33,116 having seen for myself that the Echo organ's Violone Celeste goes down to FF, not GG as stated in the contract.

The number of pipes in the instrument's contract, when signed, was 29,524 but that figure rose as stops were added during construction to 32,205. An early description of the instrument, as built, shows 33,111 pipes and a thesis on it lists 32,928. Volume One of David Junchen's Encyclopedia of the American Theatre Organ states that there are 32,967 pipes.

The truth of the matter is that the number is somewhere between 29,092 and 33,893. These figures are based on a very minimal interpretation of the scheme (i.e. with no 73 or 85-note chests which, in fact, do exist) and a somewhat grand interpretation of it (e.g. all celestes going down to the CC note which we know is not the case). Both schemes are unrealistic but they give an idea of what the outer limits must be. The bottom line is this: Regardless of which of the ten figures listed here you choose to believe, the one thing they all prove is that the instrument has more pipes than any other organ.

Note 3: Analysis of Contents / Some Facts and Figures
In terms of pipes, the largest department is the Great, followed by the Swell, enclosed Choir, and String II. In terms of ranks and pipes, the strings are the biggest group of stops, after the Principals. Of the 314 voices, flues account for 73% (reeds 27%). Of the 449 ranks, flues account for 82% (reeds 18%). The department with the least number of pipes is the Gallery IV organ.
VoicesRanks
Principals and Diaphones:77(25.4%)170(37.9%)
Diminutive Foundations, e.g. Dulciana, Gemshorn:21(6.7%)26(5.8%)
Open Flutes, including Ocarina & open Tibias:49(15.6%)53(11.8%)
Stopped Flutes, including stopped Tibias:16(5.1%)16(3.6%)
Strings, including Gamba Tubas:67(21.3%)100(22.3%)
Chorus reeds, e.g. Tuba, Trombone, Trumpet, Tromba:47(15.0%)47(10.5%)
Orchestral-type reeds, e.g. Saxophone, Clarinet, Oboe:25(8.0%)25(5.6%)
Other reeds, e.g. Vox Humana, Kinura:12(3.8%)12(2.7%)
Totals:314449
Although the official number of voices is 314, it's actually 315. This is because the Mixture on the Unenclosed Choir was to be a single stop of four ranks. In the event, it was divided into two stops of two ranks each but both retained the stop number for the original four-rank voice, i.e. 170.

"Flute" appears in 36 stop names and so does "Celeste". The string stops include 17 Viols, 12 Violins, 11 Cellos, 10 Violas, five Gambas, plus the three Gamba Tubas. There are also seven Trombas, six Trombones, five Tubas (excluding Gamba Tubas), three Posaunes, and two Ophicleides. Plus six Voxes (including the Baryton), five Clarinets, four Oboes, three Saxophones, two Krummhorns, and two Kinuras. There are 58 flute stops (excluding Tibias); 46 open and 12 stopped. Of the seven Tibias, three are open and four are stopped.

Among the 71 voices that include 16-foot pitch, eight are stopped. All manual doubles are duplexed to their respective Pedal divisions, except the Quintaton (Unenclosed Choir), Double Diapason II, Double Diapason III, Trumpet (Great), and the Trombone (Brass Chorus). These five stops, plus the Pedal Left's Major Diapason, are the only straight 16-foots. The instrument's other 212 straight stops consist of 135 8-foots, 31 4-foots, a dozen 2-foots, 10 mutations at various pitches, and 24 mixtures. The number of extended voices/ranks in the instrument is 96 that's 30.5% of the 314 voices and 21.3% of the 449 ranks. In other words: The majority of the instrument is straight.

In total, there are 53 compound stops, i.e. 24 mixtures and 29 two-rank celestes. There are 17 one-rank celeste stops (five diminutive foundations, five flutes, and seven strings). The 20 Principal-class mixtures comprise 113 ranks just over one-quarter of the total number of ranks. A further 17 ranks are to be found in four other mixtures, i.e. #225 Mixture Aetheria VI (Dulciana tone), #183 Flute Mixture III, #247 Harmonic Mixture III (flute tone), and #285 String Mixture V.

Note 4: Current Condition
At present, only the Right Stage chamber's departments are playable. These are are the Pedal Right (home of the 64-foot and the 100-inch Ophicleide), Pedal Second Touch, Pedal Percussion, Great, Great-Solo, Grand Great, Solo, and Solo-Great. The chamber contains 96 voices, 132 ranks, and 9,759 pipes. As a mean average, these account for almost one-third of the instrument's resources. There are also 19 percussions; three melodic and 16 non-melodic. A programme to replace all of the magnets in this chamber has recently been undertaken, with the result that reliability has been greatly improved.

During 2013, all of the Swell organ was removed; pipes, chests, windlines, everything no easy feat with 4,000-plus pipes spread over five levels in an enclosure that's 47 feet high! The chests have been made good and, at the time of writing (December 2013), are being re-installed in the chamber. The pipes will now be cleaned, etc. It is hoped that the Swell organ will become operational again during 2014 making just-under 50% of the instrument playable. Other departments in this area (Pedal Left, Unenclosed Choir, Swell-Choir, String I) will then be considered for restoration.

The condition of some of the more-remote departments is, frankly, shocking. There is water damage in some chambers and pipes have collapsed or been stood-on in others. It's a sad sight. Nevertheless, there is very little that is beyond redemption.
Introduction Pedal Right Pedal Left Pedal Right Gallery Pedal Left Gallery Pedal Couplers Pedal Percussion Pedal 2nd Touch
Unenclosed Choir Choir Choir-Swell Grand Choir Choir 2nd Touch Great Great-Solo Grand Great Great 2nd Touch
Swell Swell-Choir Solo Solo-Great Fanfare Echo Bombard Gallery I Gallery II Gallery III Gallery IV
Brass Chorus String I String II String III Tremolos Notes Bottom of Page Top of Page
To visit the Organ Page on Boardwalk Hall's website, click here.
